C-3
DeviceNet Connection Hardware Appendix C
Appendix C
Shielded T-branch Connectors
One-branch Power Supply Tap
Model Specifications Manufacturer
DCN2-1 One-branch shielded T-branch connectors, three micro-size (M12) connectors OMRON
DCN3-11 One-branch shielded T-branch connectors, three mini-size connectors
DCN3-12 One-branch shielded T-branch connectors, two mini-size connectors and one
micro-size (M12) connector
Model Specifications Manufacturer
DCN-1P One-branch tap for power supply. Use this tap when connecting a communica-
tions power supply.
Includes two XW4B-05C1-H1-D parallel connectors with screws and two fuses
as standard.
A Terminating Resistor (included as standard) can be connected.
OMRON
