Omron E5C-T Series Communications Manual

2 CompoWay/F Communications Procedures
2 - 4
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
The following examples show the end code when a command did not end normally.
Example 1) Illegal Sub-address, No SID, and No Command Text
• Command
• Response
End code is “16” (sub-address error).
The sub-address error code is used because the sub-address error has a higher error detection
priority than the format error.
Example 2) No Command Text
• Command
• Response
The end code is “14” (format error).
Example 3) No Node Number Provided
• Command
The node number is lacking one character.
• Response
There is no response.
2-1-4 Communications Data
Communications
format
Set (monitor)
values
Negative values Decimal point
CompoWay/F 8-digit hexadecimal 2's complement Decimal point is removed and the result is
converted to hexadecimal.
Example conversion: 105.0 → 1050 →
H'0000041A
2-1-5 End Code Example
STX 0 A ETX
BCC
Node number Sub-address
A ETX
BCC
16STX 0
Node number
Sub-address
End code
STX 0 0 ETX
BCCSID
0
Node number Sub-address
0ETX
BCC
14STX 0
Node number
Sub-address
End code
STX ETX
BCC
