Omron E5C-T Series Communications Manual

2 - 17
2 CompoWay/F Communications Procedures
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
2-3 Detailed Description of the Services
2
2-3-8 Operation Command
• Service Request PDU
• Service Response PDU
(1) Command Code and Related Information
2-3-8 Operation Command
• Communications Writing • RUN/RESET • AT Execute/Cancel
• Write Mode • Save RAM Data • Software Reset
• Move to Setup Area 1 • Move to Protect Level • Auto/Manual Switch
• Parameter Initialization • Alarm Latch Cancel • SP Mode
• Invert Direct/Reverse
Operation
• Hold • Advance
Command code Command content Related Information
00
Communications Writing 00: OFF (disabled)
01: ON (enabled)
01
RUN/RESET 00: Run
01: RESET
03
AT Execute/Cancel 0E: All PID 40% AT Execute
0F: All PID 100% AT Execute
00: AT cancel
01: 100% AT execute
02: 40% AT execute
04
Write Mode 00: Backup
01: RAM write mode
05 Save RAM Data 00
06 Software Reset 00
07 Move to Setup Area 1 00
08 Move to Protect Level 00
09
Auto/Manual Switch 00: Automatic mode
01: Manual mode
0B Parameter Initialization 00
0C
Alarm Latch Cancel 00: Alarm 1 latch cancel
01: Alarm 2 latch cancel
02: Alarm 3 latch cancel
03: HB alarm latch cancel
04: HS alarm latch cancel
05: Alarm 4 latch cancel
0F: All alarm latch cancel
0D
SP Mode 00: Program SP mode
01: Fixed SP mode
0E
Invert Direct/Reverse Operation 00: Not invert
01: Invert
MRC SRC
3005
22
2
2
Com-
mand
code
Related
informa-
tion
MRC SRC
3005
22 4
Response
code
