Omron E5C-T Series Communications Manual

5 - 3
5 Communications Data for Modbus
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
5-1 Variable Area (Setting Range) List
5
0502 2501 Initial
Setting/Communications
Protect
H'00000000 (0): Move to initial setting/communications setting
level is allowed. (Move to advanced function
setting level is displayed.)
H'00000001 (1): Move to initial setting/communications setting
level is allowed. (Move to advanced function
setting level is not displayed.)
H'00000002 (2): Move to initial setting/communications setting
level is prohibited.
Protect
0504 2502 Setting Change Protect H'00000000 (0): OFF (Changing of setup on controller display is
allowed.)
H'00000001 (1): ON (Changing of setup on controller display is
prohibited.)
0506 2503 PF Key Protect H'00000000 (0): OFF
H'00000001 (1): ON
0508 2504 Move to Protect Level H'FFFFF831 to H'0000270F (−1999 to 9999)
050A 2505 Password to Move to
Protect Level
H'FFFFF831 to H'0000270F (−1999 to 9999)
(Can only be set. The monitor value is always H’00000000.)
050C 2506 Parameter Mask Enable H'00000000 (0): OFF
H'00000001 (1): ON
0600 2600 Manual MV Standard Models
Standard control:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to 105.0)
Position-proportional Models
Close position-proportional control with the Direct Setting of
Position Proportional MV parameter set to ON:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Manual
control
0608 2604 Heater Current 1 Value
Monitor
H'00000000 to H'00000226 (0.0 to 55.0) Operation
060A 2605 MV Monitor (Heating) Standard control: H'FFFFFFCE to H'0000041A
(−5.0 to 105.0)
Heating and cooling control: H'00000000 to H'0000041A
(0.0 to 105.0)
060C 2606 MV Monitor (Cooling) H'00000000 to H'0000041A (0.0 to 105.0)
060E 2607 Valve Opening Monitor H'FFFFFF9C to H'0000044C (−10.0 to 110.0)
0610 2608 Program No. H'00000000 to H'00000007 (0 to 7)
0612 2609 Segment No. Monitor H'00000000 to H'0000001F (0 to 31)
0614 260A Remaining Standby Time
Monitor
H'00000000 to H'00009959 (hours, minutes)
H'00000000 to H'00009923 (days, hours)
0616 260B Elapsed Program Time
Monitor
H'00000000 to H'00009959
0618 260C Remaining Program Time
Monitor
H'00000000 to H'00009959 None
061A 260D Elapsed Segment Time
Monitor
H'00000000 to H'00009959
061C 260E Remaining Segment Time
Monitor
H'00000000 to H'00009959
061E 260F Program Execution
Repetitions Monitor
H'00000000 to H'0000270F (0 to 9999) Operation
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
