Omron E5C-T Series User Manual

5 Advanced Operations
5 - 50
E5@C-T Digital Temperature Controllers User’s Manual (H185)
z Setting the Upper Limits of the Zones for the PID Sets (PID Setting Level)
1 Press the M Key several times in the PID Setting Level to
select the PID 1 Automatic Selection Range Upper Limit
parameter.
PID Setting Level
2 Press the U or D Key to set 200.
The default is the input indication range upper limit.
3 Also set the PID 2 and 3 Automatic Selection Range Upper
Limit parameters in the same way.
* You cannot set the PID 4 Automatic Selection Range Upper Limit
parameter.
PID Setting Level
PID Setting Level
Refer to 4-1-4 Moving to the PID Setting Level for the procedure to enter the PID Setting Level.
z Setting the Reset Operation (Initial Setting Level)
1 Press the M Key several times in the Initial Setting Level to
select the Reset Operation parameter.
Initial Setting Level
2 Press the U or D Key to set stop (stop control).
The default is stop (stop control).
Refer to 4-1-1 Moving to the Initial Setting Level for the procedure to enter the Initial Setting Level.
z Setting the PID Set Automatic Selection Data (Advanced Function
Setting Level)
1 Press the M Key several times in the Advanced Function
Setting Level to select the PID Set Automatic Selection Data
parameter.
Advanced Function Setting
Level
2 Press the U or D Key to set pv (process value).
The default is pv (process value).
Refer to 4-1-6 Moving to the Advanced Function Setting Level for the procedure to enter the
Advanced Function Setting Level.
1320
1.aut
PID 1 Automatic
Selection Range
Upper Limit
200
1.aut
400
2.aut
PID 2 Automatic
Selection Range
Upper Limit
500
3.aut
PID 3 Automatic
Selection Range
Upper Limit
stop
rtsm
Reset Operation
stop
rtsm
pv
pidi
PID Set
Automatic
Selection Data
pv
pidi
