4 - 43
4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-7 Setting Programs
4
4-7-5 Creating the Program
z Setting Example
This parameter specifies the PID set to use for the program.
z Related Parameters
z Setting Example
Set the alarm value for the alarm to use.
z Related Parameters
The following example shows how to set 0.40.
Operating Procedure
1 Specify a segment number for the Display Segment Selection
parameter and press the M Key several times to select the
Segment Time parameter.
Program Setting Level
2 Press the U or D Key to set 0.40.
The default is 0.00.
Setting the PID Set No. Parameter
Parameter name Display Setting range Default Level
PID Set No.
pid
0: Automatic selection
1 to 8: PID set number
1 Program Setting Level
The following example shows how to set the PID set number to 2.
Operating Procedure
1 Press the M Key several times in the Program Setting Level to
select the PID Set No. parameter.
Program Setting Level
2 Press the U or D Key to set 2.
The default is 1.
Setting the Alarm Value Parameter
Parameter name Display Setting range Default Level
Alarm Value 1 to 4
al-1 to 4 -1999 to 9999
0 Program Setting Level
0.00
time
Segment 1
Time
0.40
time
1
pid
PID Set No.
2
pid
