3-1 Basic Application Flow
The following figure shows the basic flow for using the Digital Controller.
Power ON
Set the input type and other basic
settings.
Set the programs.
Set the alarm set values.
Start program operation.
*For time-proportional operation.
Set the control period* and PID constants.
• Input type
• Control method
• Alarm type Other parameters
• Make program-related settings.
Refer to 3-4 Procedures after
Turning ON the Power Supply.
To Next Page
