Omron E5CC-T User Manual

5 Advanced Operations
5 - 34
E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-12 Using the Transfer Output
A transfer output can be used on models that have a transfer output.
z Precision and User Calibration
* For details on calibration, refer to Section 6 Parameters.
Transfer Output Signal (Initial Setting Level)
You can use the Transfer Output Signal parameter to specify whether to output a current or voltage
from the transfer output.
Terminal Arrangement
z Transfer Output Type (Initial Setting Level)
You can use the Transfer Output Type parameter to specify any of five types of data to output.
*1 This function can be set for a Position-proportional Model, but the setting will be disabled.
*2 This function can be set for standard control or for a Position-proportional Model, but the setting will be
disabled.
*3 This parameter is displayed only for a Position-proportional Model.
5-12-1 Transfer Output Function
Precision User calibration
±0.3% FS Supported.*
Setting range Default
4-20: 4 to 20mA
4-20
1-5v: 1-5 V
Transfer output type Display Setting range
OFF (default) off ---
Present SP sp-m SP lower limit to SP upper limit
PV
pV
Input setting range lower limit to input setting range upper limit or
Scaling lower limit to scaling upper limit
MV monitor (heating)
*1
mV
−5.0 to 105.0 (heating/cooling control: 0.0 to 105.0)
MV monitor (cooling)
*2
c-mV
0.0 to 105.0
Valve opening
*3
V-m
−10.0 to 110.0
V
I
P
R
Q
Transfer output
V
I
Transfer output
31
33
32
E5CC-T
Option number: 006
E5EC-T/E5AC-T
Option number: 019, 020, 021, or 022
