Omron E5CC-T User Manual

6 Parameters
6 - 92
E5@C-T Digital Temperature Controllers User’s Manual (H185)
The alarm 1, 2, 3, or 4 output is prevented from turning OFF until after the delay times set in these
parameters have elapsed.
a1of
Alarm 1 OFF Delay
Alarm 1 must be assigned, and the alarm 1 type
must not be 0, 12, or 13.
a2of
Alarm 2 OFF Delay
Alarm 2 must be assigned, and the alarm 2 type
must not be 0, 12, or 13.
a3of
Alarm 3 OFF Delay
Alarm 3 must be assigned, and the alarm 3 type
must not be 0, 12, or 13.
a4of
Alarm 4 OFF Delay
Alarm 4 must be assigned, and the alarm 4 type
must not be 0, 12, or 13.
• Set the time for which the OFF delay is to be enabled.
• To disable the OFF delay, set 0.
z Related Parameters
Alarm 1 to 4 Type (Initial Setting Level): Page 6-66
mant
Manual Output Method
Control must be set to 2-PID control.
A Position-proportional Model set to Close Control
with the Direct Setting of Position-proportional MV
parameter set to ON must be used.
If this parameter is set to HOLD when control moves from Automatic Mode to Manual Mode,
the final MV from Automatic Mode will be used as the initial manual MV. If this parameter is
set to INT, the setting of the Manual MV Initial Value parameter will be used as the initial
manual MV.
z Related Parameters
Manual MV Initial Value (Advanced Function Setting Level): 6-93
Function
Setting
Setting range Unit Default
0 to 999 Seconds 0
See
See
Function
Setting
Setting range Default
hold: HOLD, init: INIT hold
See
See
