Characteristics Table – continued from previous page
Vibration resistance
Malfunction: 10 to 55 Hz, 10 m/s
2
(approx. 1G) for 10 min each in X, Y, and Z directions
Destruction: 10 to 55 Hz, 20 m/s
2
(approx. 2G) for 2 hrs each in X, Y, and Z directions
Shock resistance Malfunction: 200 m/s
2
min. (approx. 20G), 3 times each in 6 directions
(100 m/s
2
(approx. 10G) applied to the relay)
Destruction: 300 m/s
2
min. (30G), 3 times each in 6 directions
Ambient temperature
Operating –10°C to 55°C (with no icing)/3-year warranty period: –10°C to 50°C
Storage –25°C to 65°C (with no icing)
Ambient humidity Operating 35% to 85%
Enclosure ratings
Front panel NEMA 4 for indoor use (equivalent to IP66)
Rear case IEC standard IP20
Terminals IEC standard IP00
Memory protection Non-volatile memory (number of writings: 100,000 operations)
Weight Approx. 170 g;
Adapter: approx. 10 g
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: EN61000-4-2: 4kV contact discharge (level 2)
8kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10V/m (amplitude modulated,
80 MHz to 1 GHz) (level 3)
10 V/m (pulse modulated, 900 MHz)
Immunity Conducted Disturbance: ENV50141: 10V (0.15 to 80 MHz ) (level 3)
Immunity Burst: EN61000-4-4: 2kV power-line (level 3)
2kV I/O signal-line (level 4)
Approved standards UL1092, CSA22.2 No. 14, CSA22.2 No. 1010-1
Conforms to EN50081-2, EN50082-2, EN61010-1 (IEC1010-1)
Conforms to VDE0106/part 100 (Finger Protection), when the separately-ordered terminal
cover is mounted.
J OPTION BOARD RATINGS AND CHARACTERISTICS
Model Description Specifications
E53-CKB Event input Contact input:
ON: 1 kΩ max., OFF: 100 kΩ min.
No-contact input:
ON: residual voltage 1.5 V max., OFF: leakage current 0.1 mA max.
E53-CK01
Communications
RS-232C
Transmission method: Half-duplex
E53-CK03 RS-485
Synchronization method: Start-stop synchronization (asynchronous method)
Baud rate: 1.2/2.4/4.8/9.6/19.2 kbps
E53-CKF Transfer output 4 to 20 mA:
Permissible load impedance: 500 Ω max.
Resolution: approx. 2,600 steps
Note: Event input is used for switching the target value, run or stop command, or automatic and manual mode with an external signal
input.
To Next Page
