126
Initial Setting Level Section 5-6
• For the lower-limit alarms in cases 1 and 2 above, the alarm is normal-
ly OFF if upper- and lower-limit hysteresis overlaps.
• In case 3, the alarm is always OFF.
(5) Set value: 5 (The alarm is always OFF if upper- and lower-limit alarm hys-
teresis with standby sequence overlaps.)
• Set the alarm type independently for each alarm in the “alarm 1 to 3 type”
parameters in the initial setting level. The default is 2 (Upper-limit alarm).
Related Parameters
Alarm value 1: Page 101, Alarm value upper limit 1, Alarm value lower limit 1:
Page 103 (operation level)
Stand
by sequence reset: Page 133, Alarm 1 o
pen in alarm: Page 134, Alarm
1 hysteresis: Page 135, Alarm 1 latch: Page 139
(advanced function setting
level)
• Select one of the following three alarm 2 types:
Deviation, Deviation range, or Absolute value
Refer to the alarm 1 type list.
Related Parameters
Alarm value 2: Page 102, Alarm value upper limit 2, Alarm value lower limit 2:
Page 103 (operation level)
Stand
by sequence reset: Page 133, Alarm 2 o
pen in alarm: Page 134, Alarm
2 hysteresis: Page 135, Alarm 2 latch:
Page 139 (advanced function setting
level)
• Select one of the following three alarm 3 types:
Deviation, Deviation range, or Absolute value
Refer to the alarm 1 type list.
Related Parameters
Alarm value 3: Page 102, Alarm value upper limit 3, Alarm value lower limit 3:
Page 104
(operation level)
See
See
alt2 Alarm 2 Type
Alarm 2 must be assigned.
Function
Setting
See
See
alt3 Alarm 3 Type
Alarm 3 must be assigned.
Function
Setting
See
See
■
■
■
