xviii
QOther Functions
QCharacteristics
QCommunications Specifications
QHeater Burnout/HS Alarm Characteristics
Item Previous models Improved models
Display --- Display character switch (7-segment/11-segment)
Input Temperature input shift (1-point shift for temperature
input)
Temperature input shift (2-point shift also possible for
temperature input)
Output --- Manual outputs
--- Loop break alarm
Control Control period: 1 to 99 s Control period: 0.5 or 1 to 99 s
Alarm --- Alarm delays
Item Previous models Improved models
Sampling period 500 ms 250 ms
Item Previous models Improved models
Communications proto-
cols
CompoWay/F (SYSWAY) CompoWay/F (SYSWAY), Modbus
Communications baud
rate
1200, 2400, 4800, 9600, 19200 bps 1200, 2400, 4800, 9600, 19200, 38400 bps
Item Previous models Improved models
Maximum
heater
current
E5CZ E5CZ-@@M@ with E53-CNH@N
Single-phase 50 A AC
E5CZ-@@M@@ with E53-CZH@
Single-phase 50 A AC
E5AZ/EZ E5@Z-A3 + E53-AZM + E53-AZH,
E5@Z-R3 + E53-AZM + E53-AZH,
E5@Z-Q3 + E53-AZM + E53-AZH
Single-phase 50 A AC
E5@Z-@@H@@@
Single-phase 50 A AC
HS alarm
--- HS alarm

Omron E5CZ Specifications

General

Display Type	7-segment digital display
Dimensions	48 x 48 x 78 mm
Number of Control Outputs	1
Ambient Operating Temperature	-10 to 55°C
Control Method	PID control, ON/OFF control
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Alarm Output	1 or 2 (depending on model)
Setting Resolution	0.1 or 1 (depending on input type)
Protection Rating	IP20
Ambient Operating Humidity	25% to 85% RH (non-condensing)
