Omron E5CZ - Parameter Operation Lists

163
Appendix A
Parameter Operation Lists
Universal-input:Controllers with Thermocouple/Resistance Thermometer Universal-inputs
Analog input:Controllers with Analog Inputs
Operation Level
Parameters Characters Setting (monitor) value Display Default Unit Set value
Process Value Sensor input indication range EU
Set Point SP lower limit to SP upper
limit
0EU
Auto/Manual Switch a-m
Multi-SP Set Point
Setting
m-sp 0 to 3 0 None
Set Point During SP
Ramp
sp-m SP lower limit to SP upper
limit
EU
Heater Current 1
Value Monitor
ct1 0.0 to 55.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
RUN/STOP r-s RUN/STOP run, stop Run None
Alarm Value 1 al-1 −1999 to 9999 0 EU
Alarm Value Upper-
Limit 1
al1h −1999 to 9999 0 EU
Alarm Value Lower-
Limit 1
al1l −1999 to 9999 0 EU
Alarm Value 2 al-2 −1999 to 9999 0 EU
Alarm Value Upper-
Limit 2
al2h −1999 to 9999 0 EU
Alarm Value Lower-
Limit 2
al2l −1999 to 9999 0 EU
Alarm Value 3 al-3 −1999 to 9999 0 EU
Alarm Value Upper-
Limit 3
al3h −1999 to 9999 0 EU
Alarm Value Lower-
Limit 3
al3l −1999 to 9999 0 EU
MV Monitor (Heat-
ing)
o −5.0 to 105.0 (standard)
0.0 to 105.0 (heating/cooling)
%
MV Monitor (Cool-
ing)
c-o 0.0 to 105.0 %
