54
Using HB and HS Alarms Section 3-10
3-10-6 Settings (HS Alarm)
To activate the HS alarm, set the “HS alarm use” parameter to ON in the
advanced function setting level and set the “HS alarm 1” parameter in the
adjustment level.
Operating Procedure This procedure sets the “HS alarm 1” parameter to 2.5.
Moving to the Advanced Function Setting Level
The “HS alarm use” parameter setting is already ON by default, so set the
“HS alarm 1” parameter.
9. For this example, set 2.5. To return to the operation level, press the O
key for less than one second.
hb1
2.5
Operation Level
1. Move to the advanced function setting level.
Press the O key for at least three seconds to move from the operation
level to the initial setting level.
Initial Setting Level
2. Select “move to advanced function setting level” by pressing the M key.
Initial Setting Level
3. Press the D key to enter the password (169), and move from the initial
setting level to the advanced function setting level.
Advanced Function Setting Level
The top parameter in the advanced function setting level is displayed.
4. Select the “HS alarm use” parameter by pressing the M key.
Check that this parameter is set to ON (the default).
Next, set the “leakage current 1 monitor” parameter.
C
25
100
PV/SP
in-t
5
Input type
amov
-169
Moves to ad-
vanced function
setting level
init
off
hsu
on
HS alarm
use
