Omron E5CZ User Manual

128
Initial Setting Level Section 5-6
This parameter selects the output type for linear current outputs.
• Select either 4 to 20 mA or 0 to 20 mA when control output 1 is a current
output.
Note Even when control output 1 is used as a control output or a simple transfer
output, 0 to 20 mA can be used.
Related Parameter
Transfer output type (initial setting level): Page 127
• Set the “move to advanced setting level” parameter set value to “−169.”
• Move to the advanced setting level either by pressing the M key or O
key or by waiting for 2 seconds to elapse.
Related Parameter
Initial setting/communications protect (protect level): Page 96
o1-t Linear Current Output
A current output must be assigned.
Linear current
output
Default
4-20: 4 to 20 mA
0-20: 0 to 20 mA
4-20
Function
Setting
See
See
amov Move to Advanced Function Setting Level
The “initial setting/communications
protect” parameter must be set to 0.
Function
See
See
■
■

Omron E5CZ Specifications

General

Display Type	7-segment digital display
Dimensions	48 x 48 x 78 mm
Number of Control Outputs	1
Ambient Operating Temperature	-10 to 55°C
Control Method	PID control, ON/OFF control
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Alarm Output	1 or 2 (depending on model)
Setting Resolution	0.1 or 1 (depending on input type)
Protection Rating	IP20
Ambient Operating Humidity	25% to 85% RH (non-condensing)
