Appendix A
HB and HS Alarms (for Controller with Heater Burnout and HS Alarms)
Note (1) When the control output 1 ON time is less than 190 ms, heater burnout detection and heater current
measurement are not performed.
(2) When the control output 1 OFF time is less than 190 ms, HS alarm and leakage current measure-
ment are not performed.
Characteristics
Max. heater current 50 A AC
Input current indication accuracy ±5% FS ±1 digit max.
Heater burnout alarm setting
range
0.1 to 49.9 A (in units of 0.1A)
0.0 A: Heater burnout alarm output turns OFF.
50.0 A: Heater burnout alarm output turns ON.
Min. detection ON time: 190 ms (See note 1.)
HS alarm setting range 0.1 to 49.9 A (in units of 0.1A)
0.0 A: HS alarm output turns ON.
50.0 A: HS alarm output turns OFF.
Min. detection OFF time: 190 ms (See note 2.)
Indication accuracy
(ambient temperature of
23°C)
Thermocouple (See note 1.):
E5CZ/AZ/EZ: (±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max.
E5CZ-U: (±1% of indication value or ±2°C, whichever is greater) ±1 digit max.
Platinum resistance thermometer:
(±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max.
Analog input: ±0.5% FS ±1 digit max.
CT input: ±5% FS ±1 digit max.
Temperature variation
influence (See note 2.)
Thermocouple (R, S, B)
(±1% of PV or ±10°C, whichever is greater) ±1 digit max. (E5CZ)
(±2% of PV or ±10°C, whichever is greater) ±1 digit max. (E5CZ-U)
Other thermocouples:
(±1% of PV or ±4°C, whichever is greater) ±1 digit max. (E5CZ)
(±2% of PV or ±4°C, whichever is greater) ±1 digit max. (E5CZ-U)
*K thermocouple at −100°C max: ±10°C max.
Platinum resistance thermometer:
(±1% of PV or ±2°C, whichever is greater) ±1 digit max.
Analog input: ±1% FS ±1 digit max. (See note 2.)
Voltage variation influence
(See note 2.)
Hysteresis Controllers with Thermocou-
ple/Resistance Thermome-
ter Universal-inputs
0.1 to 999.9°C or °F)
(in units of 0.1°C or °F) (See note 3.)
Controllers with Analog
Inputs
0.01% to 99.99% FS (in units of 0.01% FS)
Proportional band (P) Controllers with Thermocou-
ple/Resistance Thermome-
ter Universal-inputs
0.1 to 999.9°C or °F)
(in un
its of 0.1 EU) (See note 3.)
Controllers with Analog
Inputs
0.1% to 999.9% FS (in units of 0.1% FS)
Integral time (I) 0 to 3,999 s (in units of 1 s)
Derivative time (D) 0 to 3,999 s (in units of 1 s)
Control Period 0.5, 1 to 99 s (in units of 1 s)
Manual reset value 0.0% to 100.0% (in units of 0.1%)
Alarm setting range −1,999 to 9,999 (decimal point position depends on input type)
Sampling period 250 ms
Affect of signal source resis-
tance
Thermocouple:0.1°C/ Ω max.(100 Ω max.)(See note 4.)
Platinum resistance thermometer:0.4°C/ Ω max.(10 Ω max.)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 2,000 VAC, 50/60 Hz for 1 min between terminals of different charge
Malfunction vibration
10 to 55 Hz, 20 m/s
2
for 10 min each in X, Y and Z directions
Vibration resistance 10 to 55 Hz, peak height amplitude of 0.75 mm for 2 hr each in X, Y, and Z directions
Malfunction shock
100 m/s
2
, 3 times each in X, Y, and Z directions
