173
Appendix A
• The default is 5 (°C/°F) for Controllers with Thermocouple/Resistance Thermometer Universal-inputs and
0 for Controllers with Analog Inputs.
• The applicable standards for each of the above input ranges are as follows:
K, J, T, E, N, R, S, B: JIS C1602-1995, IEC 584-1
L: Fe-CuNi, DIN 43710-1985
U: Cu-CuNi, DIN 43710-1985
JPt100: JIS C 1604-1989, JIS C 1606-1989
Pt100: IEC 751
Control Range
• Resistance thermometer and thermocouple input
Temperature lower limit − 20°C to temperature upper limit + 20°C, or temperature lower limit − 40°C to
temperature upper limit + 40°C
• ES1B input:
Same as input indication range
• Analog input
−5% to +105% of scaling range
Control-
lers with
Analog
Inputs
Current input 4 to 20 mA 0 Any of the following ranges,
by scaling:
−1999 to 9999
−199.9 to 999.9
−19.99 to 99.99
−1.999 to 9.999
−5% to 105% of setting
range. The display shows
−1999 to 9999 (numeric
range with decimal point
omitted).
0 to 20 mA 1
Voltage input 1 to 5 V 2
0 to 5 V 3
0 to 10 V 4
Input type Specifications Set value Input temperature range Input indication range
