23
Wiring Terminals Section 2-2
Input • Make the connections as shown below, using terminals 3 to 5 for the
E5CZ, pins 1 to 3 for the E5CZ-U, and pins 18 to 20 for the E5AZ/EZ, and
matching the input types.
Control Output 1 • Outputs are sent from terminals 1 and 2 with the E5CZ, from pins 4 to 6
with the E5CZ-U, and from pins 3 and 4 with the E5AZ/EZ. The following
diagrams show the available outputs and their internal equalizing circuits.
• The following table shows the specifications for each output type.
E5CZ/CZ-U
E5CZ
E5CZ-U
+
−
5
4
3
5
4
3
5
4
3
+
−
1
2
3
1
2
3
Thermocouple
Platinum resistance
thermometer
Analog input Thermocouple
Platinum resistance
thermometer
+
+
−
V
mA
−
−
+
+
−
mA
V
+
−
E5AZ/EZ
Thermocouple
Platinum resistance
thermometer
Analog input
18
19
20
20
20
19
19
18
18
A
B
B
A
B
B
A
B
B
Output type Specifications
Relay 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Voltage (PNP) PNP type, 12 VDC ±15%, 21 mA (with short-circuit protec-
tion)
Current
(Not for E5CZ-U)
DC 4 to 20 mA, resistive load: 600 Ω max.
Resolution: Approx. 2,700
E5CZ E5CZ-U
1
2
1
2
L
+
−
6
5
4 4
6
5
+
−
GND
GND
L
+V
+V
+
−
−
1
2
+
+V
L
Relay Voltage Current Relay Voltage
+
v
L
+
−
L
+
v
+
−
E5AZ/EZ
Relay Voltage Current
GND
