Omron E5EC User Manual

3 Part Names and Basic Procedures
3 - 2
E5@C Digital Temperature Controllers User’s Manual (H174)
3-1 Basic Application Flow
The following figure shows the basic flow for using the Digital Controller.
Power ON
• Input type
• Control method
• Alarm type
Other parameters
Set the set point.
Set the alarm set values.
Operate with the set values.
*For time-proportional operation.
Set the control hysteresis.
Set the control periods* and PID constants.
ON/OFF Control
PID Control
Set the input type and other basic
settings.
Refer to 3-4 Procedures after
Turning ON the Power Supply.

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
