4 Basic Operation
4 - 12
E5@C Digital Temperature Controllers User’s Manual (H174)
List of Input Types
The default is 5.
* This range can be used only for E5CC-U Digital Controllers and only if they are manufactured in May 2014 or
later (version 2.2 or higher).
Precautions for Correct Use
s.err (S.ERR: input error) flashes on the display if a sensor is not connected or if the connected
sensor is different from input type. Connect a sensor if one is not already connected.
Specifications Set value Temperature range in °C Temperature range in °F
Resistance
thermometer
Pt100 0 −200 to 850 −300 to 1500
1 −199.9 to 500.0 −199.9 to 900.0
2 0.0 to 100.0 0.0 to 210.0
JPt100 3 −199.9 to 500.0 −199.9 to 900.0
4 0.0 to 100.0 0.0 to 210.0
Thermocouple
K
5 −200 to 1300 −300 to 2300
6 −20.0 to 500.0 0.0 to 900.0
J7−100 to 850 −100 to 1500
8 −20.0 to 400.0 0.0 to 750.0
T9−200 to 400 −300 to 700
10 −199.9 to 400.0 −199.9 to 700.0
E11−200 to 600 −300 to 1100
L12−100 to 850 −100 to 1500
U13−200 to 400 −300 to 700
14 −199.9 to 400.0 −199.9 to 700.0
N15−200 to 1300 −300 to 2300
R 16 0 to 1700 0 to 3000
S 17 0 to 1700 0 to 3000
B 18 0 to 1800 0 to 3200
C/W 19 0 to 2300 0 to 3200
PLII 20 0 to 1300 0 to 2300
Infrared
temperature
sensor ES1B
10 to 70°C 21 0 to 90 0 to 190
60 to 120°C 22 0 to 120 0 to 240
115 to 165°C 23 0 to 165 0 to 320
140 to 260°C 24 0 to 260 0 to 500
Current input
4 to 20 mA 25 One of the following ranges according to the scaling:
−1999 to 9999
−199.9 to 999.9
−19.99 to 99.99
−1.999 to 9.999
0 to 20 mA 26
Voltage input
1 to 5 V 27
0 to 5 V 28
0 to 10 V 29
0 to 50 mV* 30
0.0
s.err
