Omron E5EC User Manual

5 - 35
5 Advanced Operations
E5@C Digital Temperature Controllers User’s Manual (H174)
5-12 Performing Manual Control
5
5-12-1 Manual MV
*1 The manual MV setting must be saved (see page Applying Changes to Numeric Values on page 3-9), but
values changed with key operations are reflected in the control output immediately.
• Setting the Manual MV with the S Key
1 Press the S Key in the Operation Level to enter the Manual
Control Level.
Operation Level
2 Press the U or D Key to set the manual MV.
(In this example, the MV is set to 50%.)
*1
PV/MV
0.0
25
50.0
25

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
