Setting Example to Output 1 to 5 V for the Process Value (−50 to 200°C,
Input Type 5)
Operating Procedure
• Setting the Transfer Output Signal Type
1 Press the M Key several times in the Initial Setting Level to
display trst (Transfer Output Signal Type).
Initial Setting Level
2 Press the U or D to select 1-sv (1 to 5 V).
The default is 4-20.
• Setting the Transfer Output Type
1 Press the M Key several times in the Initial Setting Level to
display tr-t (Transfer Output Type).
Initial Setting Level
2 Press the U or D Key to select pv (Process Value).
The default is off.
• Setting the Transfer Output Upper Limit
1 Press the M Key several times in the Initial Setting Level to
display tr-h (Transfer Output Upper Limit).
Initial Setting Level
2 Press the U or D Key to set the value to 200.
The default is 1300.
• Setting the Transfer Output Lower Limit
1 Press the M Key several times in the Initial Setting Level to
display tr-l (Transfer Output Lower Limit).
Initial Setting Level
2 Press the U or D Key to set the value to −50.
The default is −200.
off
trst
Transfer Output
Signal Type
1-sv
trst
off
tr-t
Transfer Output
Type
pv
tr-t
1300
tr-h
Transfer Output
Upper Limit
200
tr-h
-200
tr-l
Transfer Output
Lower Limit
-50
tr-l

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
