Page #296 background imageLoading...
Page #296 background image
6 Parameters
6 - 26
E5@C Digital Temperature Controllers User’s Manual (H174)
These parameters set the set points when the multi-SP function is used.
sp-0
SP 0
The Number of Multi-SP Points parameter must be
set to 2 to 8 and the Event Input 1 Assignment to
Event Input 6 Assignment parameters must not be
set to “Multi-SP No. switching bit 0” to “Multi-SP
No. switching bit 2.”
sp-1
SP 1
sp-2
SP 2
sp-3
SP 3
sp-4
SP 4
sp-5
SP 5
sp-6
SP 6
sp-7
SP 7
The values set in these parameters can be selected by operating the keys on the front panel
or by using event inputs.
When the set point has been changed, the set value of the set point (0 to 7) selected by
the multi-SP inputs is also changed to the same value.
The decimal point position depends on the selected sensor. During analog input, it
depends on the Decimal Point parameter setting.
Related Parameters
Process Value/Set Point (Operation Level): Page 6-8
Input Type (Initial Setting Level): Page 6-43
Event Input Assignment (Initial Setting Level): Page 6-57
Number of Multi-SP Points (Advanced Function Setting Level): Page 6-63
Function
Setting
Setting range Unit Default
SP lower limit to SP upper limit EU 0
See
See
