Omron E5EC User Manual

6 Parameters
6 - 34
E5@C Digital Temperature Controllers User’s Manual (H174)
ol-h
MV Upper Limit The control must be set to 2-PID control.
The ST parameter must be set to OFF.
A Position-proportional Model must be set to close
control.
ol-l
MV Lower Limit
• The MV Upper Limit and MV Lower Limit parameters set the upper and lower limits of the
manipulated variable. When the calculated manipulated variable exceeds the upper or
lower limit value, the upper or lower limit value will be the output level.
• MV Upper Limit
• MV Lower Limit
The MV for the cooling control output during heating/cooling control is expressed as a
negative value.
 Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-45
ST (Initial Setting Level): Page 6-46
Close/Floating (Initial Setting Level): Page 6-59
Function
Setting
Control method Setting range Unit Default
Standard control
Close position-proportional control
MV lower limit + 0.1 to 105.0 % 100.0
Heating/cooling control 0.0 to 105.0
Control method Setting range Unit Default
Standard control
Close position-proportional control
−5.0 to MV upper limit − 0.1 % 0.0
Heating/cooling control −105.0 to 0.0 −100.0
See
See

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
