Omron E5EC User Manual

6 - 83
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-8 Advanced Function Setting Level
6
*3 Can be selected when the Program Pattern parameter is set to OFF, but the function will be
disabled.
*4 WR1 to WR8 are not displayed when the logic operation function is not used.
*5 If the Digital Controller is equipped with HB/HS alarm detection, it is set by default to ha (Heater
Alarm).
alma
Integrated Alarm Assignment The integrated alarm must be assigned.
You can use the integrated alarm to output an OR of alarm 1, alarm 2, alarm 3, alarm 4, the
HB alarm, the HS alarm, the input alarm, and the RSP input alarm. Set this parameter to the
sum of the codes of the status for which to output an OR.
The default is 49 (i.e., an OR of alarm 1, the HB alarm, and the HS alarm is output). The
alarm 1 code is 1, the HB alarm code is 16, and the HS alarm code is 32: 1 + 16 + 32 = 49.
 Related Parameters
Alarm Value 1 to 4 (Operation Level): Page 6-14
MV at Error (Adjustment Level): Page 6-33
HB ON/OFF (Advanced Function Setting Level): Page 6-65
HS Alarm Use (Advanced Function Setting Level): Page 6-77
Remote SP Enable (Advanced Function Setting Level): Page 6-85
Function
Setting
Code Status
+1 Alarm 1
+2 Alarm 2
+4 Alarm 3
+8 Alarm 4
+16 HB alarm
+32 HS alarm
+64 Input error
+128 RSP input error
Setting range Default
0 to 255 49
See
See

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
