Omron E5EC User Manual

1 Introduction
1 - 12
E5@C Digital Temperature Controllers User’s Manual (H174)
 E5DC-B (Models with Push-In Plus Terminal Blocks)
*1 The options that can be selected depend on the type of control output and number of auxiliary outputs.
*2 The control output can be used as a simple transfer output.
(1) (2) (3) (4) (5) (6) (7) Meaning
D 22.5 mm wide and mounts to DIN Track
Control output 1
*1 R X Relay output
*1 Q X Voltage output (for driving SSR)
*1*2 C X Linear current output
*1 0 None
*1 2 2
A 100 to 240 VAC
D 24 VAC/DC
B Push-In Plus terminal blocks
M Universal input
Event inputs Communications HB alarm and HS alarm
000 --- --- ---
002 --- RS-485 1
015 --- RS-485 ---
Control output
No. of auxiliary
outputs
Options
000 002 015
RX or QX 0 --- --- Selectable
2 Selectable Selectable ---
CX 0 --- --- Selectable
2 Selectable --- Selectable
E5DC
B
(1) (2) (3) (4) (5) (6) (7)
−−
Size
Control Output 1
No. of auxiliary outputs
Power supply voltage
Terminal type
Input type
Options

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
