Digital Temperature Controllers E5GN 5
■ Characteristics
Note: The indication of K thermocouples in the −200 to 1300°C range, and T and N thermocouples at a temperature of −100°C or less, and U and
L thermocouples at any temperature is
±2°C±1 digit maximum. The indication of B thermocouples at a temperature of 400°C or less is un-
restricted.
The indication of R and S thermocouples at a temperature of 200
°C or less is ±3°C±1 digit maximum.
Indication accuracy Thermocouple:
(
±0.5% of indicated value or ±1°C, whichever greater) ±1 digit max. (see note)
Platinum resistance thermometer:
(
±0.5% of indicated value or ±1°C, whichever greater) ±1 digit max.
Analog input:
±0.5% FS±1 digit max.
Hysteresis 0.1 to 999.9 EU (in units of 0.1 EU)
Proportional band (P) 0.1 to 999.9 EU (in units of 0.1 EU)
Integral time (I) 0 to 3999 s (in units of 1 s)
Derivative time (D) 0 to 3999 s (in units of 1 s)
Control period 1 to 99 s (in units of 1 s)
Manual reset value 0.0% to 100.0% (in units of 0.1%)
Alarm setting range
−1999 to 9999 (decimal point position depends on input type)
Sampling period 500 ms
Insulation resistance 20 M
Ω min. (at 500 VDC megger)
Dielectric strength 2000 VAC, 50 or 60 Hz for 1 min (between different charging terminals)
Vibration resistance
10 to 55 Hz, 10 m/s
2
for 2 hours each in X, Y and Z directions
Shock resistance
300 m/s
2
, 3 times each in 3 axes, 6 directions (relay: 100 m/s
2
)
Weight Approx. 90 g Mounting bracket: approx. 10 g
Degree of protection Front panel: NEMA4X for indoor use (equivalent to IP66), rear case: IP20, terminals: IP00
Memory protection EEPROM (non-volatile memory) (number of writes: 100,000)
EMC ESD Immunity: IEC 61000-4-2:
4 kV: Contact discharge
8 kV: Air discharge
Radiated Electromagnetic Field Immunity: IEC 61000-4-3
10 V/m (80 MHz to 1 GHz amplitude modulated)
Burst Immunity: IEC 61000-4-4:
2 kV: Power lines
1 kV: I/O signal lines
Surge Immunity: IEC 61000-4-5:
1 kV: Normal mode (power lines and output lines)
2 kV: Common mode (power lines and output lines)
Conducted Disturbance Immunity: IEC 61000-4-6:
3 V: (0.16 to 80 MHz)
Voltage Dip/Interrupting Immunity: IEC 61000-4-11
0.5 cycle, 100% (rated voltage)
Radiated Emission: EN 61326 Class A
Conducted Emission: EN 61326 Class A
Approved standards UL 61010C-1 (Listing)
CSA C22.2 No. 1010.1 (Evaluated by UL.)
Compliant standards EN 61010-1: 2001
IEC 61010-1: 2001

Omron E5GN Specifications

General

Brand	Omron
Model	E5GN
Category	Temperature Controller
Language	English
