J ACCESSORIES
E89-F3 Mounting Bracket
Two-3.5 (0.14) dia.
* Provided wi th E8F 2
Four-R1 (R0.04 )
13.5
(0.53)
9
(0.35)
20.5
(0.81)
20 (0.79)
20
(0.79)
26.9
(1.06)
1.6
(0.06)
4.5
(0.18)
27 (1.06)
14.5
(0.57)
15±0.4
(0.59)
Two-3.5 (0.14)dia.
R7.25 (R0.29)
Four-R2.5 (R0.10)
R1.6 (R0.06)
J E89-F4 PANEL-MOUNTING BRACKET (SOLD SEPARATELY)
0
Panel
Panel Cutout Dimensions
(E89-F4 is available in the following two sizes.)
Spacer not mounted Spacer mounted
33
+0.5
40
(1.57)
Note: The spacer can be removed from the panel-
mounting bracket. The panel cutout dimen-
sions can be adjusted as shown above by
attaching or detaching the spacer.
(1.30
+0.02
)
36
+0.5
33
+0.5
(1.42
+0.02
)
(1.42
+0.02
)
0
0
0
0
0
0
0
36
+0.5
41.3 (1.63)
20
(0.79)
11.5
(0.45)
25 (0.98)
4
(0.16)
Panel
Spacer
40 (1.57)
20.65 (0.81)
12.15
(0.48)
(1.30
+0.02
)
17
(0.67)
