(OHFWURPDJQHWLF,PPXQLW\(1
Immunity test
(1
WHVWOHYHO
Compliance
OHYHO
(OHFWURPDJQHWLFHQYL-
ronment - guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Floors should be wood,
concrete or ceramic tile.
If floors are covered
with synthetic material,
the relative humidity
should be at least 30 %.
Electric fast
transient/burst
IEC 61000-4-4
±2 kV for
power supply
lines
±1 kV for
input/output lines
±2 kV for
power supply
lines
±1 kV for
input/output lines
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV
normal mode
±2 kV
common mode
±1 kV
normal mode
±2 kV
common mode
Mains power quality
should be that of a
typical commercial or
hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
0 % U
T
; 0.5 cycle
$WÛÛÛ
ÛÛÛ
ÛDQGÛ
0 % U
T
; 0.5 cycle
$WÛÛÛ
ÛÛÛ
ÛDQGÛ
Mains power quality
should be that of a
typical commercial or
hospital environment.
If the user of the
HBP-1120 requires
continued operation
during power mains
interruptions, it is
recommended that the
HBP-1120 be powered
from an uninterruptible
power supply or
batteries.
0 % U
T
; 1 cycle
70 % U
T
;
25/30 cycles
VLQJOHSKDVH
DWÛ
0 % U
T
1 cycle
70 % U
T
;
25/30 cycles
VLQJOHSKDVH
DWÛ
0 % U
T
;
250/300 cycles
0 % U
T
;
250/300 cycles
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m (r.m.s)
50 Hz or 60 Hz
30 A/m (r.m.s)
50 Hz or 60 Hz
Power frequency
magnetic fields
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
1RWH8
T
is the a.c. mains voltage prior to application of the test level.
