Omron JX System Configuration

2 Frequency inverters
Type designation
200 V class
400 V class
Specifications
Single-phase: JX@ AB002 AB004 AB007 AB015 AB022 - - -
Three-phase: JX@ A2002 A2004 A2007 A2015 A2022 A2037 A2055 A2075
Motor
kW
*1
*1
Based on a standard 3-Phase standard motor.
Applicable motor capacity 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Output
characteristics
Inverter capacity kVA
200 V
0.4 0.9 1.3 2.4 3.4 5.5 8.3 11.0
240 V
0.5 1.0 1.6 2.9 4.1 6.6 9.9 13.3
Rated output current (A) 1.4 2.6 4.0 7.1 10.0 15.9 24.0 32.0
Max. output voltage Proportional to input voltage: 0…240 V
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
Single-phase 200…240 V 50/60 Hz
3-phase 200…240 V 50/60 Hz
Rated input current (A) Three-phase 200 V 1.8 3.4 5.2 9.3 13.0 20.0 30.0 40.0
Rated input current (A) Single-phase 200 V 3.1 5.8 9.0 16.0 22.5 – – –
Allowable voltage
fluctuation
-15%…+10%
Allowable frequency
fluctuation
+5%
Built-in filter
EMC filter (C1 single phase)
Braking torque
At short-time
deceleration
At capacitor
feedback
Approx. 50%
50% for
3-phase
20 to 40% for
1-phase
Approx 20% to 40% Approx 20%
Cooling method
Self cooling Forced-air-cooling
Three-phase: JX@ A4004 A4007 A4015 A4022 A4040 A4055 A4075
Motor
kW
*1
*1
Based on a standard 3-Phase standard motor.
Applicable motor capacity 0.4 0.75 1.5 2.2 4.0 5.5 7.5
Output
characteristics
Inverter capacity kVA
380 V
0.9 1.6 2.5 3.6 5.6 8.5 10.5
480 V
1.2 2.0 3.1 4.5 7.1 10.8 13.3
Rated output current (A) 1.5 2.5 3.8 5.5 8.6 13.0 16.0
Max. output voltage Proportional to input voltage: 0…480 V
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
3-phase 380…480 V 50/60 Hz
Rated input current (A) 2.0 3.3 5.0 7.0 11.0 16.5 20.0
Allowable voltage
fluctuation
-15%…+10%
Allowable frequency
fluctuation
+5%
Built-in filter
EMC filter C2 class
Braking torque
At short-time
deceleration
At capacitor
feedback
Approx. 50% Approx. 20% to 40% Approx. 20%
Cooling method
Self cooling Forced-air-cooling
JX series
A: Standard specs
JXAB002-EF
Voltage:
B: Single-phase 200 VAC
2: Three-phase 200 VAC
4: Three-phase 400 VAC
Max. applicable motor output
002: 0,2 kW
~
075: 7,5 kW
F: Built-in EMC Filter
E: Europe standard

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
