Omron JX System Configuration

4 Frequency inverters
IP 20 type 0.2 to 7.5 kW
Rasmi footprint Filters
Filter only needed by the 1-phase 200 V or 3-phase 400 V to comply with C1 EMC class.
Dimensions
Voltage class
Max. applicable
motor output kW
Inverter model JX@ Figure
Dimensions in mm
W1 H1 W H D t1 D1 Weight
Single-phase
200 V
0.2 AB002 1
67 143 80 155
95.5
2.6
13 0.8
0.4 AB004
1
109.5 27 0.9
0.75 AB007
2
98 176 110 189
130.5 28 1.5
1.5 AB015 2
157.5 6 55
2.3
2.2 AB022 2 2.4
Three-phase
200 V
0.2 A2002 1
67 143 80 155
95.5
2.6
13 0.8
0.4 A2004 1 109.5 27 0.9
0.75 A2007 1 132.5 50 1.1
1.5 A2015 2
98 176 110 189 157.5 6 55
2.2
2.2 A2022 2
2.4
3.7 A20372
5.5 A2055 2
164 235 180 250 167.5 1.6 77.5 4.2
7.5 A2075 2
Three-phase
400 V
0.4 A4004 2
98 176 110 189
130.5 2.6 28 1.5
0.75 A4007 2
157.5 6 55
2.3
1.5 A4015 2
2.42.2 A4022 2
4.0 A4040 2
5.5 A4055 2
164 235 180 250 167.5 1.6 77.5 4.2
7.5 A4075 2
Figure 1
Figure 2
6
5
5
W
H1
W1
H
t1
D1
1.9
D
H1
5
H
W1
W
5
6
t1
D1
D
1.9
Rasmi model
Dimensions
Weight
kg
W H L X Y M
1x200 V
AX-FIJ1006-RE 81 40 193 183 57 M4 0.5
AX-FIJ1010-RE 112 47 226 216 88 M4 0.6
AX-FIJ1026-RE 112 47 226 216 88 M4 0.8
3x200 V
AX-FIJ2006-RE 81 50 193 183 57 M4 1.0
AX-FIJ2020-RE 112 50 226 216 88 M4 1.3
AX-FIJ2040-RE 182 55 289 279 150 M5 2.3
3x400 V
AX-FIJ3005-RE 112 45 226 216 88 M4 0.9
AX-FIJ3011-RE 112 45 226 216 88 M4 1.1
AX-FIJ3020-RE 182 45 289 279 150 M4 1.7

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
