Omron JX System Configuration

JX 5
Input AC Reactor
DC Reactor
Output AC Reactor
Chokes
Voltage Reference
Dimensions Weight
kg
A
B2 C2 D E F
200 V
AX-RAI02800080-DE 120 70 120 80 52 5.5 1.78
AX-RAI00880175-DE 120 80 120 80 62 5.5 2.35
AX-RAI00350335-DE 180 85 190 140 55 6 5.5
400 V
AX-RAI07700042-DE 120 70 120 80 52 5.5 1.78
AX-RAI03500090-DE 120 80 120 80 62 5.5 2.35
AX-RAI01300170-DE 120 80 120 80 62 5.5 2.50
Voltage Reference
Dimensions Weight
kg
A
B C D E F G H
200 V
AX-RC21400016-DE
84 113
96
101 66 5 7.5 2
1.22
AX-RC10700032-DE
AX-RC06750061-DE
105 1.60
AX-RC03510093-DE
AX-RC02510138-DE
116 1.95
AX-RC01600223-DE
108 135 124 120 82 6.5
9.5
9.5 3.20
AX-RC01110309-DE
120 152
136
13594 7 -
5.20
AX-RC00840437-DE
146 6.00
400 V
AX-RC43000020-DE
84 113
96
101 66 5 7.5 2
1.22
AX-RC27000030-DE
105 1.60
AX-RC14000047-DE
AX-RC10100069-DE
116 1.95
AX-RC06400116-DE
108 135133 120 82 6.5
9.5
9.5 3.70
AX-RC04410167-DE
120 152
136
13594 7 -
5.20
AX-RC03350219-DE
146 6.00
Voltage Reference
Dimensions Weight
kg
A
B2 C2 D E F
200 V
AX-RAO11500026-DE 120 70 120 80 52 5.5 1.78
AX-RAO07600042-DE 120 70 120 80 52 5.5 1.78
AX-RAO04100075-DE 120 80 120 80 62 5.5 2.35
AX-RAO03000105-DE 120 80 120 80 62 5.5 2.35
AX-RAO01830180-DE 180 85 190 140 55 6 5.5
AX-RAO01150220-DE 180 85 190 140 55 6 5.5
AX-RAO00950320-DE 180 85 205 140 55 6 6.5
400 V
AX-RAO16300038-DE 120 70 120 80 52 5.5 1.78
AX-RAO11800053-DE 120 80 120 80 52 5.5 2.35
AX-RAO07300080-DE 120 80 120 80 62 5.5 2.35
AX-RAO04600110-DE 180 85 190 140 55 6 5.5
AX-RAO03600160-DE 180 85 205 140 55 6 6.5
X
H
YW
Ø m
L
Ø d
Reference D
diameter
Motor
KW
Dimensions Weight
kg
L W H X Y m
AX-FER2102-RE 21 < 2.2 85 22 46 70 - 5 0.1
AX-FER2515-RE 25 < 15 105 25 62 90 - 5 0.2

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
