1 Introduction
1-8
MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual
1-6 Part Number Structure
F320-F Part Number Structure
Use this legend when defining product part numbers. Please note that not all combinations of parameters are valid. For instance, fixed focus distance
of 50 mm is not available with Narrow Lens. When ordering, use valid part numbers from the tables in the Ordering Information section only.
F320-F[XXX][Y][ZZZ]-NN[P]
Example Part Number:
• F320-F050W50C-NNV: Fixed Focus at 50 mm, Wide Lens, 5 MP Color, No Light, Visionscape (Full AutoVISION and Visionscape Toolsets)
F320-F Valid Product Matrix
Key Classification Code Meaning
XXX Focus Distance (mm) 050 Fixed Focus at 50 mm
064 Fixed Focus at 64 mm
081 Fixed Focus at 81 mm
102 Fixed Focus at 102 mm
133 Fixed Focus at 133 mm
190 Fixed Focus at 190 mm
300 Fixed Focus at 300 mm
Y Lens W Wide Field of View - 5.2 mm Focal Length Lens
M Medium Field of View – 7.7 mm Focal Length Lens
N Narrow Field of View – 16 mm Focal Length Lens
ZZZ Sensor 03M 752 x 480 (0.3 MP) Pixel, Mono Sensor, Global Shutter
12M 1280 x 960 (1.2 MP) Pixel, Mono Sensor, Global Shutter
50C 2592 x 1944 (5 MP) Pixel, Color Sensor, Rolling Shutter
L Light Type N No Outer Light
C Light Color N No Outer Light
P Software License S AutoVISION Sensor (Vision Toolset Only)
A AutoVISION (Vision and Code Reading / Verification Toolsets)
V Visionscape (Full AutoVISION and Visionscape Toolsets)
Model Category Focus Type Sensor Lens Focus Distance (mm) Light License
F320-F
Monochrome Fixed Focus 03M, 12M W, M 50, 64, 81, 102, 133, 190, 300 None S, A, V
Color Fixed Focus 50C W, M 50, 64, 81, 102, 133, 190, 300 None S, A, V
Monochrome Fixed Focus 03M, 12M N 64, 81, 102, 133, 190, 300 None S, A, V
Color Fixed Focus 50C N 64, 81, 102, 133, 190, 300 None S, A, V
