Appendix A - Connector Pinouts
A-6
MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual
A-4-2 Connector B - M12 8-Pin Socket - Ethernet
Pin Function
1V+
2 V–
3 V–
4 TX (–)
5 RX (+)
6 TX (+)
7 V+
8 RX (–)
