Omron NA Series Practices Guide

14
４-１ Import Projects
1. Set the PC’s IP address to
192.168.1.100.
Make sure that the IP address
of your PC does not overlap
with IP addresses of devices
that configures the connected
system.
2. Start Sysmac Studio.
Note: Sysmac Studio Ver. 1.25
must be installed in advance.
3. Select [Import].
4. The dialog box shown on the
right appears. Select a project
file of the safety CPU demo
screen and click [Open].
5. The project file is imported
and opened automatically.

Omron NA Series Specifications

General

Touch Panel	Resistive
Interfaces	USB, Ethernet, RS-232/422/485
Operating Temperature	0°C to 50°C
Power Supply	24 VDC
Protection Rating	IP65 (front panel)
Storage Temperature	-20°C to 60°C
Display Type	TFT LCD
Dimensions	Varies depending on the model
Weight	Varies depending on the model
