Omron NA Series Practices Guide

6
Table of Contents
Terms and Conditions Agreements ...................................................... 3
１ Related Manuals ............................................................................. 7
２ Precautions ..................................................................................... 8
３ Overview ......................................................................................... 9
３ - １ Functions and Features ................................................................................. 9
３ - ２ Demonstration Configuration ....................................................................... 10
３ - ３ Project Files and Supporting Range ............................................................ 11
４ Preparation for Demo Screen ...................................................... 13
４ - １ Import Projects ............................................................................................. 14
４ - ２ Set NA Clock................................................................................................ 15
４ - ３ Add Devices ................................................................................................. 18
４ - ４ Transfer Projects to NA ................................................................................ 20
４ - ５ Prepare Setting Files ................................................................................... 21
５ Demonstration Procedures .......................................................... 24
５ - １ Monitoring on Safety I/O LEDs..................................................................... 24
５ - ２ Register and Confirm Safety Signature ........................................................ 26
５ - ３ Display Data Logging Results ...................................................................... 31
５ - ４ Restore Safety Programs in Sites ................................................................ 40
６ Appendix: Specifications ............................................................. 49
６ - １ Screen Overview .......................................................................................... 49
６ - ２ Screen Transition and Security Levels ......................................................... 52
６ - ３ Screen Specification Details ........................................................................ 53
Revision History ................................................................................... 68

Omron NA Series Specifications

General

Touch Panel	Resistive
Interfaces	USB, Ethernet, RS-232/422/485
Operating Temperature	0°C to 50°C
Power Supply	24 VDC
Protection Rating	IP65 (front panel)
Storage Temperature	-20°C to 60°C
Display Type	TFT LCD
Dimensions	Varies depending on the model
Weight	Varies depending on the model
