Omron NA Series Practices Guide

16
5. Click [OK].
6. Select the Online icon in the
Toolbar.
If NA’s version is 1.09 or earlier, it
must be upgraded when
connected online.
Upgrade the current NA version
following to a dialog.
After upgrading is completed, NA
will be reset. Select Online icon in
the Toolbar again.
7. Click [HMI] – [HMI Clock].
8. Select a proper time zone. Then
click [Apply].
9. Click [Yes].

Omron NA Series Specifications

General

Touch Panel	Resistive
Interfaces	USB, Ethernet, RS-232/422/485
Operating Temperature	0°C to 50°C
Power Supply	24 VDC
Protection Rating	IP65 (front panel)
Storage Temperature	-20°C to 60°C
Display Type	TFT LCD
Dimensions	Varies depending on the model
Weight	Varies depending on the model
