5-3-2 Graphic Display
NA reads the results of data logging and displays them in a trend graph form.
1. Press [Safety CPU Demo
Screen].
2. Press the [DataLogFileView]
button.
3. Select the data log file that you
want to display.
4. Press the [DataLog Result View]
button.
5. The variables logged in the file
are listed. Select variables to
display.
