NB-series Programmable Terminals Startup Guide Manual(V109)
1-1 Models of NB Series
There are 7 models of NB series PTs available now: NB3Q-TW00B/TW01B, NB5Q-TW00B/TW01B,
NB7W-TW00B/TW01B and NB10W-TW01B.
With TFT display used, NB series has higher cost performance. The LED backlight used is more
environmentally-friendly, energy-efficient and with longer service life compared to traditional CCFL
backlight. The display device of NB series (PT: Programmable Terminals) can be used for information
display and receive-input operation. It can show operating states of the system and devices in graphic
forms to users.
z Major Parameters
Note NB7W is used as the abbreviated name of NB7W-TWB hereinafter.
Models
NB3Q NB5Q NB7W NB10W
TW00B TW01B TW00B TW01B TW00B TW01B TW01B
Performance Specifications
Display Size 3.5”TFT LCD 5.6”TFT LCD 7”TFT LCD 10”TFT LCD
Resolution QVGA 320×240 QVGA 320×234 WVGA 800×480
Display Color 65536 colors
Backlight LED
Memory 128M FLASH + 64M DDR2 RAM
(NB-TW01B supports the USB storage)
Downloading Programs USB / Serial Port / Network Interface
(Only NB-TW01B supports the network interface downloading)
USB Port Equivalent of USB 2.0 Full speed
NB-TW00B: USB Slave ×1
NB-TW01B: USB Slave ×1, USB Host ×1
Communication
Ports
Serial
Port
COM1: RS-232C/
422A/485
COM1: RS-232C
COM2: RS-232C/422A/485
Network
Interface
Only supported by the HMI of NB-TW01B
Electrical Specifications
Rated Power 5W 9W 6W 10W 7W 11W 14W
Rated Voltage DC24V
Structural Specifications
Case Color Black
Dimensions
W×H×D(mm)
129.8×103.8×52.8 184.0×142.0×46.0 202.0×148.0×46.0 268.8×210.8
×54.0
Weight 310g 315g 620g 625g 710g 715g 1545g
Software Tools
Version No. NB-Designer Ver1.2X
For download the application programs, please access your local Omron website. If
local site cannot be found, please access Omron IA global site
“http://www.ia.omron.com/” at first and select the area where you are.
