6 Maintenance and Troubleshooting
NB-series Programmable Terminals Startup Guide Manual(V109)
6-3 Troubleshooting
6
6-3-1 Software Trouble
Select [Password] for the Data Type in the attributes page of [Numeric Data], as follows:
The process is the same for changing other system parameters online. But note that after changing the
following system parameters, the HMI needs to be rebooted to validate the changes.
System Parameter Setting: the following addresses will take effect after reboot.
Addresses Descriptions comments
10010 Initial Window number 0~65535
10011 Screen saver (backlight saver) 0 (OFF, Constant, Screen saver inactivated)
1~600 minutes (activated)
10013 Common window/Pop-up window 0: Normal
1: Higher than other windows
10014 Common window/attribute 0: Lower than the Base window
1: Higher than the Base window
10015 Storage event number 0~65535
10016 RTC source 0: PLC(Local Word)
1: Internal RTC
10017 Default language 0~3
10018 System reserve HMI internal use
