4 Connecting to Schneider PLCs
4-6
NB-series Programmable Terminals Host
Connection Manual (V108)
PL7 Software Setting
1
Open “Programs”
menu - Select [XWAY Driv
er Manager] from Modicon
Telemecanique:
2
Select [UNITELWAY Driver] tab and push [Config
u
ration] in the dialog box and finally select
[Edit] in the following d
ialog box to modify th
e related setttings of the com
munications.
PLC Settings
107
109
