Omron NB10W-TW01B - Supported Registers

11-7
11 Connecting to Keyence PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
11-4 Supported Registers
11
11-4 Supported Registers
KV-3000
KV-5000
Device Bit Address Word Address Format Notes
Input, Output, Internal
Relay
R0-999.15 ------ DDD.DD
Internal auxiliary Relay MR0-999.15 ------ DDD.DD
Control Relay CR0-39.15 ------ DD.DD
Latch Relay LR0-999.15 ------ DDD.DD
Data Memory ------ DM0-65534 DDDDD
Extended Data
Memory
------ EM0-65534 DDDDD
Temporary Data
Memory
------ TM0-511 DDD
Control Memory ------ CM0-5999 DDDD
File Register ------ FM0-32767 DDDDD
Device Bit Address Word Address Format Notes
Input, Output, Internal
Relay
R0-999.15 ------ DDD.DD
Internal auxiliary Relay MR0-999.15 ------ DDD.DD
Control Relay CR0-39.15 ------ DD.DD
Latch Relay LR0-999.15 ------ DDD.DD
Data Memory ------ DM0-65534 DDDDD
Extended Data
Memory
------ EM0-65534 DDDDD
Temporary Data
Memory
------ TM0-511 DDD
Control Memory ------ CM0-5999 DDDD
File Register ------ FM0-32767 DDDDD
