2 Connecting to SIEMENS PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
2-3 Communication Parameter Setting
2
2-3-3 SIEMENS S7-200 (SMART) Ethernet (TCP Slave)
4 Make settings of IP address and others and select the [Auto Detect Communications] for the
[Module Connection Type].
When completing the settings, click the [Next>] button.
5 Make settings as below and click the [Next>] button.
