79
DST1 Series Monitoring Section 4-7
Monitor value: 1: ON, 0: OFF Status value: 1: Normal, 0: Error
Operation result: 1: ON, 0: OFF
For details on overall status, refer to 4-7-4 Monitoring the DST1-XD0808SL-1.
+5 Reserved Reset
request sig-
nal
Safety input
operation
result No. 5
Safety input
operation
result No. 4
(4/5)
Safety input
operation
result No. 3
Safety input
operation
result No. 2
(2/3)
Safety input
operation
result No. 1
Safety input
operation
result No. 0
(0/1)
+6 Overall status
Offset
(bytes)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
