Omron NP3 Series

4-4 Creating Screens
4
4
86 NP Introduction Manual
Creating Screens
4. Click .
You will see the lamp of the ON status.
5. Set lamp properties.
* Select [Bold] from the toolbar.
●Button (Change Screen)
This button is used to switch to the [06 Check1] screen.
1. Select [Objects] - [Button] - [Change Screen] from the main menu. Move
the mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
A button frame will show.
3. Set button properties.
* Select [Bold] from the toolbar.
Item Setting
Label OPEN*
Label Size 10
Label Color (White)RGB(255,255,255)
Foreground Color (Black)RGB(16,16,16)
Item Setting
Label Previous [line break] Screen*
Label Size 20
Label Color (White)RGB(255,255,255)
Foreground Color (Black)RGB(16,16,16)
Change Screen 6-06 Check1
