4-4 Creating Screens
4
4
NP Introduction Manual 87
Creating Screens
āOther Objects
Create remaining objects by copy function.
For details, refer to [06 Check1].
Change the properties as below.
a
* Setting for the ON status.
b
* Setting for the ON status.
c
* Set this property after creating the [08 Check3] screen.
Object Item Setting
Fixed Object (Text) Label STOP Switch
Lamp (N-state)
Read Address Internal Memory:$0.01
Label STOP
Label STOP*
Object Item Setting
Fixed Object (Text) Label CLOSE Switch
Lamp (N-state)
Read Address Internal Memory:$0.02
Label CLOSE
Label CLOSE*
Object Item Setting
Button (Change Screen)
Label Next [line break] Screen
Change Screen 8-08 Check3*
