Omron NP3 Series

4-4 Creating Screens
4
4
90 NP Introduction Manual
Creating Screens
●Fixed Object (Text)
Create the "I/O Check" and "TIM0" text objects.
For details, refer to [01 Waiting].
Use these settings.
I/O Check
* Select [Bold] and [Center] from the toolbar.
TIM0
* Select [Bold] and [Center] from the toolbar.
●Input (Numeric Input)
1. Select [Objects] - [Input] - [Numeric Input] from the main menu. Move the
mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
An input frame will show.
3. Set the numeric input properties.
Item Setting
Label I/O Check*
Label Size 24
Label Color (Black)RGB(16,16,16)
Foreground Color (White)RGB(255,255,255)
Item Setting
Label TIM0*
Label Size 32
Label Color (Black)RGB(16,16,16)
Foreground Color (White)RGB(255,255,255)
Item Setting
Write Address SERIALA:TIM00000
Read Address SERIALA:TIM00000
Label Size 40
Border Color (Black)RGB(16,16,16)
Foreground Color (White)RGB(255,255,255)
Style Standard
Leading Zero Yes
Detail [Input Value] dialog box (Data Format: BCD)
