Omron NP3 Series

4-4 Creating Screens
4
4
NP Introduction Manual 91
Creating Screens
●Button (Change Screen)
This button is used to switch to the [07 Check2] screen.
1. Select [Objects] - [Button] - [Change Screen] from the main menu. Move
the mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
A button frame will show.
3. Set button properties.
●Button (System Menu)
This button is used to switch to the system menu.
1. Select [Objects] - [Button] - [System Menu] from the main menu. Move the
mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
A button frame will show.
3. Set button properties.
Item Setting
Label Previous [line break] Screen
Label Size 20
Label Color (White)RGB(255,255,255)
Foreground Color (Black)RGB(16,16,16)
Change Screen 7-07 Check2
Item Setting
Label System [line break] Menu
Label Size 20
Label Color (White)RGB(255,255,255)
Foreground Color (Black)RGB(16,16,16)
