Omron NTXS - Omron Cable Diagrams for Serial Cables; Nt2 S-Cn232-V1; Nt2 S-Cn235-V1

Appendix
171
4 Omron Cable Diagrams for Serial cables
4.1 NT2S-CN232-V1 / NT2S-CN235-V1
DB9 MALE
PINOUTS
UNIT
NTXS SIDE
OMRON PLC SIDE
2 mtr.
ATTACH
PLC
SIGNALS
TXD
RXD
SG
Shield Wire
Pin #
1
2
3
4
5
6
7
8
9
SIGNALS
TXD
RXD
RTS
CTS
SG
Pin #
1
2
3
4
5
6
7
8
9
Shield Wire to
DB9 Body
DB9 MALE
(RS232)
DB9 MALE
(RS232)
Shield Wire
69
1
5
