Omron NTXS - Keyence Kv Plc to Ntxs Unit

Appendix
186
12 KEYENCE KV PLC TO NTXS UNIT
UNIT
NTXS SIDE
KEYENCE KV
PLC SIDE
2 mtr.
Pin #
1
2
3
4
5
6
7
8
9
SIGNALS
TXD
RXD
SG
DB9 MALE
(RS232)
Pin #
1
2
3
4
SIGNALS
TXD
SG
RXD
6X4 MODULAR
CONNECTOR (RS232)
DB9 MALE
PINOUTS
8 PIN MODULAR CONNECTOR
PINOUTS
6
9
1
5
Cable insert
end
Cable insert
end
Pin 1
(Left side)
Pin 4
(Right side)
FRONT VIEW
R.H.S. VIEW
Shield Wire
Shield Wire
